Metal Powder Sintered Porous Elements Ycrh-SSP
Ycrh-SSP is the metal powder sintered porous filter tube with a small diameter and symmetrical pore (SSP) structure in the tube-wall thickness direction. This kind of filter tube is fabricated by a special technique combined with isostatic cold pressing and high-vacuum sintering.
1) Features
The size and distribution of pores are adjusted by choosing the right metal powder particles. There are no adhesives added in the fabrication process. This kind of filter tube is very suitable for the applications of cross-flow filtration and separation process.
2) Properties
High shape stability
Thermal stability up to 650°C
High corrosion resistance
High permeability and low pressure drop
Small range of pore size distribution
Welding and machining are possible
3) Specifications
Connection: thread, flange, flat pressing, quick connection, etc.
Material Selection: 316L; 304L; 310S; 321, 904L; Hastelloy alloys; Inconel 600; Inconel 625; Monel 400
